Description

By combining state-of-the-art temperature resistance with the unprecedented ability to vary the mechanical properties of finished parts, SL 5530 gives you the power to tackle a wide variety of high temperature and adverse testing applications. USE IT FOR HIGH-TEMPERATURE APPLICATIONS. SL 5530 delivers the highest heat resistance of any SLA system build material available today on a solid state machine, withstanding temperatures in excess of 200°C (392°F). It’s ideal for high-temperature applications — including automotive under-the-hood testing, composite autoclave tooling, high-temperature RTV molding, and more. NEW — TUNE MECHANICAL PROPERTIES SIMPLY BY VARYING BUILD STYLES. Use the FASTTM build style to gain both faster throughput and the highest possible heat deflection temperature; or use the EXACTTM build style for accuracy and green strength. Use both build styles in a single model to put the appropriate properties precisely where you need them. Only 3D Systems offers you this option.

Additional information

Specification: Accura SL 5530

Header

Accura SL 5530

Brand

3D Systems

Material name

Accura SL 5530

Technology

SLA / DLP

How it comes

Resin

Properties

3D Printer Resins

General material type

Resin

Material group specific material type

High Temp Resin

Colour

Transparent

Datasheet

https://dl.airtable.com/8NGzd8P6RC9g2nOIGQNd_3Qss83SDS1WNLdESV1Wl_SL5530_7000.pdf

Tensile strength yield xy in mpa

57

Elongation at break xy

3

Flexural strength xy in mpa

109

Flexural modulus xy in mpa

2972

Impact strength

Low

Shore hardness shore d a

88 D

Glass transition temperature

82

Heat deflection temperature 0 45mpa

68

Heat deflection temperature 1 82mpa

56

Density g cm

1.25
