AlSi10Mg-0403
Description
AlSi10Mg-0403 alloy comprises aluminium alloyed with silicon of mass fraction up to 10%, small quantities of magnesium and
iron, along with other minor elements. The presence of silicon makes the alloy both harder and stronger than pure aluminium
due to the formation of Mg
2
Si precipitate.
Due to the natural formation of an oxide layer on the surface of the aluminium alloy, the material has high corrosion resistance
which can be further improved by chemically anodising.
Additional information
Specification: AlSi10Mg-0403
| Header | AlSi10Mg-0403 |
|---|---|
| Model number | AlSi10Mg-0403 |
| Brand | Renishaw |
| Material name | AlSi10Mg-0403 |
| Technology | DMLS / SLM |
| How it comes | Metal Powder |
| General material type | Metal |
| Material group specific material type | Aluminium |
| Am process | Powder Bed Fusion |
| Colour | Metallic |
| Datasheet | https://dl.airtable.com/fj7jGPkMSLmAzD2XcoGO_AlSi10Mg-0403_200_W_material_data_sheet.pdf |
| Tensile strength ultimate xy in mpa | 316 |
| Tensile strength yield xy in mpa | 236 |
| Elongation at break xy | 5 |
| Modulus of elasticity xy in mpa | 78000 |
| Vickers hardness hv | 116HV05 |
| Melting temperature | 570 |
| Density g cm | 2.68 |
| Legal disclaimer | 3DC LTD is not liable for the accuracy of the information contained within this database. Please consult directly with the relevant machine and/or material manufacturers before determining fitness for a particular use. |
