Description

Through continuous interaction with our customers, pattern makers and foundries,
Somos

developed the groundbreaking stereolithography resin Somos

Element
the new standard for producing Investment Casting patterns.
Somos

Element is an antimony-free stereolithography material that has been
specifically designed to improve the repeatability and quality of 3D printed casting
patterns. Patterns created with Somos

Element leave trace amounts of lightweight,
easily-removable ash residue after burnout and have good green strength, so there’s
no worry of breakage during handling, while being dimensionally stable during
storage. Any residue that is left behind is easily removed, leaving a perfectly clean
void in the ceramic mold. This translates into lower mold prep times and lower rates
of rework, saving customers time and money.

Additional information

Specification: Element

Header

Element

Brand

Somos

Material name

Element

Technology

SLA / DLP

How it comes

Resin

Properties

3D Printer Resins

General material type

Resin

Material group specific material type

Castable Resin

Colour

Transparent

Datasheet

https://dl.airtable.com/36Dz5B5CSnKixiiWm4Mo_Somos%20Element_EN_A4.pdf

Tensile strength ultimate xy in mpa

53

Elongation at break xy

2

Flexural strength xy in mpa

114

Flexural modulus xy in mpa

3230

Modulus of elasticity xy in mpa

3170

Impact strength

Low

Shore hardness shore d a

86 D

Glass transition temperature

58

Heat deflection temperature 0 45mpa

58

Heat deflection temperature 1 82mpa

53

Dielectric strength min v mm

18.3

Dielectric constant 1 khz

3.6
