High Temp RGD525
Description
High Temperature has the highest heat deflection of any PolyJet standalone material and great surface smoothness. High temperature is strong and stiff, ideal for static parts or thermal testing parts that require high heat resistance such as plumbing fixtures and household appliances.
Additional information
Specification: High Temp RGD525
| Header | High Temp RGD525 |
|---|---|
| Brand | Stratasys |
| Material name | High Temp RGD525 |
| Technology | Material Jetting |
| General material type | Resin |
| Material group specific material type | High Temp Resin |
| Am process | Material Jetting |
| Colour | Clear |
| Datasheet | https://dl.airtable.com/UHRRamloQxWtaMoyoaDq_MSS_PJ_PJMaterialsDataSheet.pdf |
| Tensile strength ultimate xy in mpa | 70 |
| Elongation at break xy | 10 |
| Flexural strength xy in mpa | 110 |
| Flexural modulus xy in mpa | 3100 |
| Modulus of elasticity xy in mpa | 3200 |
| Rockwell hardness hrc | 78 |
| Impact strength | Low |
| Shore hardness shore d a | 87 D |
| Glass transition temperature | 62 |
| Heat deflection temperature 0 45mpa | 63 |
| Heat deflection temperature 1 82mpa | 55 |
| Density g cm | 1.17 |
| Water absorption | 1 |
| Ash content | 0.38 |
| How it comes | Resin |
Legal Disclaimer
3DC LTD is not liable for the accuracy of the information contained within this database. Please consult directly with the relevant machine and/or material manufacturers before determining fitness for a particular use.
