HTM140
Description
EnvisionTEC’s HTM140 High Temperature Mold Material dramatically changes 3D printing capabilities for manufacturers. With a heat deflection temperature of 140�C straight out of the machine, high definition parts printed in HTM140 can be directly vulcanized in rubber, eliminating the need for a metal master. It is designed to withstand both the heat and pressure of vulcanizing the model in rubber with incredible detail and no loss of dimensional stability. It can also be used in a variety of applications that require thermal resistance such as items to be metallized or tested for high temperature gas and liquid applications. To add to its versatility, another use is for making tools for small run injection molding. It is easily paintable for visual aids.
Additional information
Specification: HTM140
| Header | HTM140 |
|---|---|
| Brand | EnvisionTec |
| Material name | HTM140 |
| Technology | SLA / DLP |
| How it comes | Resin |
| Properties | 3D Printer Resins |
| General material type | Resin |
| Material group specific material type | Tooling Resin |
| Colour | Green |
| Datasheet | https://dl.airtable.com/KVf91e0IQsa2bCtOuLRJ_MK-MTS-HTM140Industrial-V01-FN-EN.pdf |
| Tensile strength yield xy in mpa | 56 |
| Elongation at break xy | 4 |
| Flexural strength xy in mpa | 115 |
| Flexural modulus xy in mpa | 3350 |
| Heat deflection temperature 1 82mpa | 140 |
| Legal disclaimer | 3DC LTD is not liable for the accuracy of the information contained within this database. Please consult directly with the relevant machine and/or material manufacturers before determining fitness for a particular use. |
