ProtoTherm
Description
Somos
�
ProtoTherm 12120 stereolithography material is the perfect solution for
applications requiring resistance to heat and humidity.
Somos
�
ProtoTherm 12120 excels at producing highly detailed, extremely accurate
parts. The material is dimensionally stable when exposed to heat and humidity
making it a good candidate for high temperature fluid flow analysis, functional
prototypes, and limited run, non-critical end-use parts such as wiring harnesses and
support connectors in electronic devices.
Additional information
Specification: ProtoTherm
| Header | ProtoTherm |
|---|---|
| Brand | Somos |
| Material name | ProtoTherm |
| Technology | SLA / DLP |
| How it comes | Resin |
| Properties | 3D Printer Resins |
| General material type | Resin |
| Material group specific material type | High Temp Resin |
| Colour | Red |
| Datasheet | https://dl.airtable.com/7LFgtljPSwyPZYgg0bG2_Somos%20ProtoTherm%2012120%20SS-PDS%20-%20A4.pdf |
| Tensile strength ultimate xy in mpa | 70.2 |
| Elongation at break xy | 4 |
| Flexural strength xy in mpa | 109 |
| Flexural modulus xy in mpa | 3320 |
| Modulus of elasticity xy in mpa | 3520 |
| Impact strength | Low |
| Shore hardness shore d a | 85 D |
| Glass transition temperature | 74 |
| Heat deflection temperature 0 45mpa | 56.5 |
| Heat deflection temperature 1 82mpa | 51.9 |
| Dielectric constant 1 khz | 4.04 |
| Density g cm | 1.15 |
| Water absorption | 0.37 |
