R5
Description
R5 and R11 is a liquid photopolymer that produces robust, accurate, and functional parts. The material offers superior chemical resistance, a wide processing latitude, and excellent tolerance to a broad temperature and humidity range during and after build. Parts created from R5 and R11 exhibit superior fatigue properties, strong memory retention, and high quality up-facing and down-facing surfaces. R5 and R11 also offers a good balance of properties between rigidity and functionality.
Additional information
Specification: R5
| Header | R5 |
|---|---|
| Brand | EnvisionTec |
| Material name | R5 |
| Technology | SLA / DLP |
| How it comes | Resin |
| Properties | 3D Printer Resins |
| General material type | Resin |
| Material group specific material type | High Detail Resin |
| Colour | Red |
| Datasheet | https://dl.airtable.com/HnBk9ekT2OAdVMdBpnQA_MK-MTS-R5R11-V01-FN-EN.pdf |
| Tensile strength yield xy in mpa | 31 |
| Elongation at break xy | 11 |
| Flexural strength xy in mpa | 40 |
| Flexural modulus xy in mpa | 1190 |
| Modulus of elasticity xy in mpa | 1245 |
| Impact strength | Low |
| Shore hardness shore d a | 81 D |
| Glass transition temperature | 37 |
| Heat deflection temperature 0 45mpa | 84.5 |
| Heat deflection temperature 1 82mpa | 65.4 |
| Water absorption | 0.78 |
| Legal disclaimer | 3DC LTD is not liable for the accuracy of the information contained within this database. Please consult directly with the relevant machine and/or material manufacturers before determining fitness for a particular use. |
