Rigid Opaque Plastics
Description
Combining dimensional stability and high-detail visualization, the PolyJet rigid opaque family is intended for standard plastics simulation and model creations that closely resemble the ‘look’ of the end product.
Durable and strong, this family of Rigid Opaque photopolymers provides excellent detail visualization and is available in a variety of colors – gray, black, white and blue. You can 3D print accurate, realistic prototypes that test fit, form and function, even for moving and assembled parts.
Additional information
Specification: Rigid Opaque Plastics
| Header | Rigid Opaque Plastics |
|---|---|
| Brand | Stratasys |
| Material name | Rigid Opaque Plastics |
| Technology | |
| General material type | Resin |
| Material group specific material type | High Detail Resin |
| Am process | Material Jetting |
| Colour | Grey |
| Datasheet | https://dl.airtable.com/sSzXhC6uR7at7NGHVVoB_MSS_PJ_PJMaterialsDataSheet.pdf |
| Tensile strength ultimate xy in mpa | 50 |
| Elongation at break xy | 15 |
| Flexural strength xy in mpa | 60 |
| Flexural modulus xy in mpa | 1900 |
| Modulus of elasticity xy in mpa | 2000 |
| Impact strength | Low |
| Shore hardness shore d a | 83 D |
| Heat deflection temperature 0 45mpa | 45 |
| Heat deflection temperature 1 82mpa | 45 |
| How it comes | Resin |
Legal Disclaimer
3DC LTD is not liable for the accuracy of the information contained within this database. Please consult directly with the relevant machine and/or material manufacturers before determining fitness for a particular use.
