Ti6Al4V ELI-0406
Description
Ti6Al4V ELI-0406 alloy comprises titanium mass fraction up to 90% alloyed with aluminium up to 6.75% and vanadium up to
4.5%, along with other minor elements. Ti6Al4V grade 23 is otherwise referred to as ELI or Extra Low Interstitial with regards
to the interstitial impurities oxygen, carbon, and nitrogen. It is a higher purity version of the most commonly used titanium alloy
Ti6Al4V grade 5. The reduced interstitial elements in grade 23 lead to an increase in both ductility and fracture toughness.
Ti6Al4V ELI-0406 has excellent specific strength (strength to weight ratio) which makes it an ideal choice where weight saving
load structures are required. It has good corrosion resistance, it is also biocompatible, so can be used for a range of surgical and
dental applications. For medical and dental applications Renishaw supply Ti MG1 powder, for more infomation refer to document
H-5983-9027
Additional information
Specification: Ti6Al4V ELI-0406
| Header | Ti6Al4V ELI-0406 |
|---|---|
| Model number | Ti6Al4V ELI-0406 |
| Brand | Renishaw |
| Material name | Ti6Al4V ELI-0406 |
| Technology | DMLS / SLM |
| How it comes | Metal Powder |
| General material type | Metal |
| Material group specific material type | Titanium |
| Am process | Powder Bed Fusion |
| Colour | Metallic |
| Datasheet | https://dl.airtable.com/kpa1jk8UQO22hFSJPQgk_Ti6Al-4V_ELI-0406_material_data_sheet.pdf |
| Tensile strength ultimate xy in mpa | 1133 |
| Tensile strength yield xy in mpa | 1045 |
| Elongation at break xy | 8 |
| Modulus of elasticity xy in mpa | 116000 |
| Vickers hardness hv | 397HV05 |
| Density g cm | 4.42 |
