ULTEM 1010
Description
ULTEM 1010 resin is a high-performance FDM thermoplastic that offers excellent strength, thermal stability and the ability to withstand
steam autoclaving. ULTEM 1010 resin is available in a general-purpose grade as well as a certified grade (CG) for those customers who
want to take advantage of food-contact and bio-compatibility certifications for special applications including food production tools and
custom medical applications. ULTEM 1010 resin offers the highest heat resistance, chemical resistance and tensile strength of any FDM
thermoplastic and is ideal for aerospace and automotive applications.
Additional information
Specification: ULTEM 1010
| Header | ULTEM 1010 |
|---|---|
| Elongation at break xy | 3 |
| Material name | ULTEM 1010 |
| Technology | FDM |
| How it comes | Filament |
| General material type | Thermoplastic |
| Material group specific material type | PEI |
| Am process | Material Extrusion |
| Colour | Natural |
| Datasheet | https://dl.airtable.com/vDCGxmSEQbe4F79npwV5_MSS_FDM_ULTEM1010.pdf |
| Tensile strength ultimate xy in mpa | 81 |
| Tensile strength yield xy in mpa | 64 |
| Brand | Stratasys |
| Flexural strength xy in mpa | 144 |
| Elongation at yield xy | 2.2 |
| Flexural modulus xy in mpa | 2820 |
| Flexural strain at break xy | 3.5 |
| Modulus of elasticity xy in mpa | 2770 |
| Impact strength | Medium |
| Glass transition temperature | 215 |
| Thermal expansion m m c | 47 |
| Heat deflection temperature 0 45mpa | 216 |
| Heat deflection temperature 1 82mpa | 218 |
| Vicat softening temperature | 214 |
| Bio compatibility certification | ISO 10993,Class4 |
| Food safety certification | NSF 51,Test classification |
