Windform LX 3.0
Description
Windform® LX 3.0 is a composite polyamide based material which is reinforced with a new generation glass fiber system.
Windform® LX 3.0 has improved the already excellent performance of Windform® LX 2.0. These improvements can be noticed from a sinterability standpoint.
Windform® LX 3.0 maintains the Windform® LX 2.0’s technical and thermal properties; it is also not electrically conductive.
It is a naturally black material and is characterized by good Tensile Strength and stiffness.
Windform® LX 3.0 is also characterized by high level of temperature resistance (HDT, 1.82 Mpa is 175,9°C / 348.62 °F).
Windform® LX 3.0 has an excellent surface finish in its sintered state; it is perfect for components with fine details. Windform® LX 3.0 is highly recommended for applications that require a strong visual impact and for aesthetical parts.
Windform® LX 3.0 is an entry-level material and is perfect for creating functional prototypes or finished parts that require reliability, resistance and aesthetical properties.
Additional information
Specification: Windform LX 3.0
| Header | Windform LX 3.0 |
|---|---|
| Brand | CRP Technology |
| Material name | Windform LX 3.0 |
| Technology | SLS |
| How it comes | SLS Powder |
| General material type | Thermoplastic |
| Material group specific material type | Composite |
| Colour | Black |
| Datasheet | https://dl.airtable.com/s5pc25J8TeoGXCCcCQBE_SCHEDA_WF_LX_3_0_ENG.pdf |
| Legal disclaimer | 3DC LTD is not liable for the accuracy of the information contained within this database. Please consult directly with the relevant machine and/or material manufacturers before determining fitness for a particular use. |
